Resolution

1 μT

10 μT

100 μT

Measuring Range

2 mT～3000mT①

Accuracy

Class 1

±1.0%

Class 2

±2.0%

Class 5

±2.0% ( 2 mT...1000 mT )，±5.0% ( 1000 mT...3000 mT )

Temperature Coefficient

± 0.1% / K

Zero Drift

± 0.5 mT/h

Display Digit

5

Remark

1 Calibration only covers 2.5T

Temperature Performance

Operating temperature: 0~50℃;

Storage temperature: -20°C～70°C

Humidity Performance

Operating humidity: 40%～80% R·H, non-condensing

Storage humidity: <95% R·H, non-condensing

Weight

About 350 g

Interface

Hall probe input interface, USB interface

Overall Dimensions

90mm(W) ×40 mm(D) × 165 mm(H)

1

TM1100 Hall probe

Radial

1

Standard Accessory

2

TM1110 Hall probe

Axial

1

Optional

Note: The users should indicate the probe in the order contract.
