TUNKIA TI1100 Precision AC DC Current Calibrator

Share to:

TI1100 Precision AC DC Current Calibrator

Name: TI1100 Precision AC DC Current Calibrator
Brand: TUNKIA
SKU: 541900967
Rating: 5.0 (92 reviews)

TI1100 is an AC/DC current source with high stability and precision, it is applied for calibrating ammeters on-site, e.g, industrial production lines, etc. The measurement accuracy of current for TI1100 can achieve Class 0.01(DC) and Class 0.02(AC).

Features:	AC/DC current output: 10 μA ~ 10.5 A Frequency: DC, AC 10 Hz ~ 10 kHz Optimum Accuracy: DC 0.01, AC 0.02 Typical short-term stability: 0.005%/min
Availability:

Quantity:



Inquire Add to Basket

Model:
TI1100
Brand:
TUNKIA

TI1100 Precision AC/DC Current Calibrator

1. Summary

TI1100 is an AC/DC current source with high stability and precision, it is applied for calibrating ammeters on-site, e.g, industrial production lines, etc.

2. Features

• AC/DC current output: 10 μA ~ 10.5 A

• Standard version (TI1100-B) and advanced version (TI1100-C) are available

• Typical specifications of the standard version (TI1100-B):

Frequency: DC, AC 10 Hz ~ 2 kHz.

Typical short-term stability: 0.01%/min

Optimum Accuracy: DC 0.02, AC 0.05.

• Typical specifications of the advanced version (TI1100-C):

Frequency: DC, AC 10 Hz ~ 10 kHz

Typical short-term stability: 0.005%/min

Optimum Accuracy: DC 0.01, AC 0.02.

• Shortcut output keys.

• Programmable calibration schemes.

• RS232, LAN and USB communication interfaces.

3. Application

☆ Calibration for Current Measuring Instruments

TUNKIA TI1100 Precision AC DC Current Calibrator

• Suitable for calibrating AC/DC ammeters or current measurement of multimeter.

☆ Convenient Operation

TUNKIA TI1100 Precision AC DC Current Calibrator

• The front panel has 10 shortcut keys that can output the corresponding value on the screen with one key.

☆ Calibration Scheme Setting

TUNKIA TI1100 Precision AC DC Current Calibrator

• Multiple calibration schemes can be edited and stored for the calibration of multimeter with different specifications.

4. Specifications (TI1100-B)

4.1 DC Current Output

Range	Current Output	Resolution	Short term stability (%/min)	Accuracy ±(%*output +μA)	Compliance Voltage (V)
300 μA	±(10.0000 μA ~ 330.0000 μA)	100 pA	0.02	0.012 + 0.03	11 V
3 mA	±(0.300000 mA ~ 3.300000 mA)	1nA	0.01	0.012 + 0.24	11 V
30 mA	±(3.00000 mA ~ 33.00000 mA)	10 nA	0.01	0.012 + 2.4	9 V
300 mA	±(30.0000 mA ~ 330.0000 mA)	100 nA	0.01	0.012 + 24	7 V
1A	±(0.100000 A ~ 1.100000 A)	1μA	0.01	0.012 + 80	6 V
10 A	±(1.00000 A ~ 10.50000 A)	10 μA	0.01	0.012 + 800	4 V

• Output range: ±(10 μA ~ 10.5 A).

• 7 digits display.

• Adjustment fineness: 0.002% * RG.

• Ripple coefficient:<0.1%.

• Protection function: open circuit protection, overload protection, overheating protection.

4.2 AC Current Output

Range	Current Output	Frequency	Resolution	Accuracy ± (%*output +μA)	Compliance Voltage (rms)
300 μA	10.0000 μA ~ 330.0000 μA	10 Hz ~ 45 Hz	100 pA	0.05 + 0.2	7 V
		45 Hz ~ 400 Hz		0.03 + 0.1
		400 Hz ~ 2 kHz		0.04 + 0.2
3 mA	0.300000 mA ~ 3.300000 mA	10 Hz ~ 45 Hz	1nA	0.05 + 0.5	7 V
		45 Hz ~ 400 Hz		0.03 + 0.3
		400 Hz ~ 2 kHz		0.04 + 0.5
30 mA	3.00000 mA ~ 33.00000 mA	10 Hz ~ 45 Hz	10 nA	0.05 + 5	6 V
		45 Hz ~ 400 Hz		0.03 + 3
		400 Hz ~ 2 kHz		0.04 + 5
300 mA	30.0000 mA ~ 330.0000 mA	10 Hz ~ 45 Hz	100 nA	0.05 + 50	5 V
		45 Hz ~ 400 Hz		0.03 + 30
		400 Hz ~ 2 kHz		0.04 + 50
1A	0.100000 A ~ 1.100000 A	10 Hz ~ 45 Hz	1μA	0.05 + 150	4 V
		45 Hz ~ 400 Hz		0.03 + 100
		400 Hz ~ 2 kHz		0.04 + 150
10 A	1.00000 A ~ 10.50000 A	45 Hz ~ 400 Hz	10 μA	0.03 + 1000	2.5 V
		400 Hz ~ 2 kHz		0.04 + 1500

• Output range: ± (10 μ A ~ 10.5 A).

• 7 digits display.

• Adjustment fineness: 0.002% * RG.

• Distortion: <0.3%.

• Protection function: open circuit protection, overload protection, overheating protection.

4.3 Frequency

Range	Resolution	Accuracy (± %*RD)
10.00000 Hz ≤ F ≤ 99.99999 Hz	0.01 mHz	0.01
100.0000 Hz ≤ F ≤ 999.9999 Hz	0.1 mHz	0.01
1.000000 kHz ≤ F ≤ 2.000000 kHz	1 mHz	0.01

5. Specifications (TI1100-C)

5.1 DC Current Output

Range	Current Output	Resolution	24-hour Stability (Tcal ± 1°C)	Accuracy 1year(Tcal ± 5°C)	Compliance Voltage
Range	Current Output	Resolution	± (ppm*output + μA)
100 μA	±(10.0000 μA ~ 110.0000 μA)	100 pA	50 + 0.01	100 + 0.02	10 V
1 mA	±(0.100000 mA ~ 1.100000 mA)	1nA	40 + 0.02	80 + 0.04	10 V
10 mA	±(1.00000 mA ~ 11.00000 mA)	10 nA	30 + 0.2	60 + 0.4	9 V
100 mA	±(10.0000 mA ~ 110.0000 mA)	100 nA	30 + 2	60 + 4	7 V
1 A	±(0.100000 A ~ 1.100000 A)	1 μA	30 + 20	60 + 40	4 V
10 A	±(1.00000 A ~ 10.50000 A)	10 μA	50 + 300	100 + 500	4 V

• Output range: ± (10 μA ~ 10.5 A).

• 7 digits display.

• Adjustment fineness: 0.002% * RG.

• Ripple coefficient: <0.1%.

• Protection function: open circuit protection, overload protection, overheating protection

5.2 AC Current Output

Range	Current Output	Frequency	Resolution	Accuracy ± (%*output +μA)	Compliance Voltage (rms)
100 μA	10.0000 μA ~ 110.0000 μA	10 Hz ~ 45 Hz	100 pA	800 + 0.04	6.5V
		45 Hz ~ 2 kHz		600 + 0.04
		2 kHz ~ 10 kHz		800 + 0.1
1 mA	0.100000 mA ~ 1.100000 mA	10 Hz ~ 45 Hz	1 nA	300 + 0.1	6.5V
		45 Hz ~ 2 kHz		200 + 0.1
		2 kHz ~ 10 kHz		300 + 0.2
10 mA	1.00000 mA ~ 11.00000 mA	10 Hz ~ 45 Hz	10 nA	200 + 0.8	6 V
		45 Hz ~ 2 kHz		120 + 0.8
		2 kHz ~ 10 kHz		300 + 2
100 mA	10.0000 mA ~ 110.0000 mA	10 Hz ~ 45 Hz	100 nA	200 + 8	5 V
		45 Hz ~ 2 kHz		120 + 8
		2 kHz ~ 10 kHz		300 + 20
1 A	0.100000 A ~ 1.100000 A	10 Hz ~ 45 Hz	1μA	200 + 80	3.5 V
		45 Hz ~ 2 kHz		120 + 80
		2 kHz ~ 10 kHz		300 + 200
10 A	1.00000 A ~ 10.50000 A	10 Hz ~ 45 Hz	10 μA	200 + 1000	2.5 V
		45 Hz ~ 2 kHz		120 + 1000
		2 kHz ~ 5 kHz		300 + 2000

• Output range: ± (10 μA ~ 10.5 A).

• 7 digits display.

• Adjustment fineness: 0.002% * RG.

• Distortion:<0.5%

• Protection function: open circuit protection, overload protection, overheating protection.

5.3 Frequency

Range	Resolution	Accuracy (± %*RD)
10.00000 Hz ≤ F ≤ 99.99999 Hz	0.01 mHz	0.01
100.0000 Hz ≤ F ≤ 999.9999 Hz	0.1 mHz	0.01
1.000000 kHz ≤ F ≤ 9.999999 kHz	1 mHz	0.01
10.00000 kHz	10 mHz	0.01

6. General Specifications

Power Supply	AC (220±22) V，(50±2) Hz
Maximum Power Consumption	100 VA
Warm Up Time	Twice the time since last warmed up, to a maximum of 30 minutes.
Work Environment	0 °C~55 °C, 30% R·H~80% R·H, non-condensing
Storage Environment	-30 °C~70 °C, 10% R·H~90% R·H, non-condensing
Communication Interface	USB×1、LAN×1、RS232×1
Dimensions	215 mm (Width) x 252 mm (Depth) x 88 mm (Height), excluding feet.
Display	3.5-inch color LCD
Weight	About 5 kg
