TM2400 Solenoid

The TM2400 is a series of solenoids, which can be used as a magnetic field generator to match with a precision excitation current source to generate a DC standard magnetic field.

Availability:

Quantity:



Inquire Add to Basket

Model:
TM2400
Brand:
TUNKIA

TM2400 Solenoid

* This figure is for reference only. There may be some differences according to the technical specifications

1. Summary

The TM2400 is a series of solenoids, which can be used as a magnetic field generator to match with a precision excitation current source to generate a DC standard magnetic field.

2. Applications

• Open-circuit magnetic sample detection

• Calibration of a magnetic sensor

• Traceability calibration of the magnetometer

• Electromagnetic interference simulation experiment

• Magnetic field influence test

TM9000 Magnetometers Calibration System

TM2300 / TM2330 Helmholtz Coil

TM2000 / 2030 Precision Excitation Current Source

TM1200 / 1230 Fluxgate Probe

TM1100 / 1110 / 1130 Hall Probe

Specifications	Diameter ( mm )	Inner hole diameter ( mm )	Maximum magnetization field (G)	Homogeneous area @uniformity	Max. current ( A )	Power ( kW )
TM2400-1000mm-1250G	1000	100	1250 G	Ф500 mm@5% Ф240 mm@1% Ф160 mm@0.5% Ф80 mm@0.1%	± 25	1.8
TM2400-1000mm-1000G	1000	100	1000 G		± 25	1.5
TM2400-1000mm-750G	1000	100	750 G		± 25	1.2
TM2400-1000mm-500G	1000	100	500 G		± 25	0.6
TM2400-1000mm-200G	1000	100	200 G		± 25	0.6
TM2400-1000mm-100G	1000	100	100 G		± 25	0.3
TM2400-600mm-1250G	600	60	1250 G	Ф300 mm@5% Ф140 mm@1% Ф90 mm@0.5% Ф45 mm@0.1%	± 25	1.8
TM2400-600mm-1000G	600	60	1000 G		± 25	1.5
TM2400-600mm-750G	600	60	750 G		± 25	1.2
TM2400-600mm-500G	600	60	500 G		± 25	0.6
TM2400-600mm-200G	600	60	200 G		± 25	0.3
TM2400-600mm-100G	600	60	100 G		± 5	0.15
TM2400-300mm-750G	300	30	750 G	Ф150 mm@5% Ф70 mm@1% Ф45 mm@0.5% Ф20 mm@0.1%	± 25	0.3
TM2400-300mm-500G	300	30	500 G		± 5	0.15
TM2400-300mm-200G	300	30	200 G		± 5	0.15
TM2400-300mm-100G	300	30	100 G		± 5	0.15

Specifications	Diameter ( mm )	Inner hole diameter ( mm )	Maximum magnetization field (G)	Homogeneous area @uniformity	Max. current ( A )	Power ( kW )
TM2400-1000mm-1250G	1000	100	1250 G	Ф500 mm@5% Ф240 mm@1% Ф160 mm@0.5% Ф80 mm@0.1%	± 25	1.8
TM2400-1000mm-1000G	1000	100	1000 G		± 25	1.5
TM2400-1000mm-750G	1000	100	750 G		± 25	1.2
TM2400-1000mm-500G	1000	100	500 G		± 25	0.6
TM2400-1000mm-200G	1000	100	200 G		± 25	0.6
TM2400-1000mm-100G	1000	100	100 G		± 25	0.3
TM2400-600mm-1250G	600	60	1250 G	Ф300 mm@5% Ф140 mm@1% Ф90 mm@0.5% Ф45 mm@0.1%	± 25	1.8
TM2400-600mm-1000G	600	60	1000 G		± 25	1.5
TM2400-600mm-750G	600	60	750 G		± 25	1.2
TM2400-600mm-500G	600	60	500 G		± 25	0.6
TM2400-600mm-200G	600	60	200 G		± 25	0.3
TM2400-600mm-100G	600	60	100 G		± 5	0.15
TM2400-300mm-750G	300	30	750 G	Ф150 mm@5% Ф70 mm@1% Ф45 mm@0.5% Ф20 mm@0.1%	± 25	0.3
TM2400-300mm-500G	300	30	500 G		± 5	0.15
TM2400-300mm-200G	300	30	200 G		± 5	0.15
TM2400-300mm-100G	300	30	100 G		± 5	0.15

TM2400 Solenoid

TM2400 Solenoid

TM2400 Solenoid
